The Smart Professional Downlight delivers advanced lighting control with premium performance and flexibility. Engineered for modern residential and commercial spaces, this intelligent downlight combines cutting-edge optics with full color and temperature customisation. Flex & Plug Remote Driver included.
FEATURES Architectural spotlight. Multiple CCT options from 2700K to 5000K
DIMENSIONS
O82mm x H105mm
O115mm x H140mm
CUT-OUT
O75mm
O100mm
POWER 36V
WATTAGE 8W, 12W, 15W, 25W
IP RATING IP44, IP65
CRI 90+
LED CCT 2700K, 3000K, 4000K
TUNABLE WHITE 2700K - 6500K
DIM TO WARM 3000K - 1800K
BEAM ANGLE 15, 21, 26, 38, 50 Degrees
FINISHES White Trim, Black Trim
REFLECTORS Black Nickel, Shinning Gold, Shinning Silver, Matt Black, Matt White
DIMMING Triac, DALI, Casambi
ACCESSORIES Honey Comb
WARRANTY 5 years
TECHNICAL DATA
Photometric Files | 8W 3000K 15D
Photometric Files | 8W 3000K 21D
Photometric Files | 8W 3000K 26D
Photometric Files | 8W 3000K 38D
Photometric Files | 8W 3000K 50D
IES Files | 8W 3000K 15D
IES Files | 8W 3000K 21D
IES Files | 8W 3000K 26D
IES Files | 8W 3000K 38D
IES Files | 8W 3000K 50D
